BETTER MISSION MAGNUM REPLACEMENT IMPELLER

BETTER MISSION MAGNUM REPLACEMENT IMPELLER BETTER MISSION MAGNUM REPLACEMENT IMPELLER BETTER MISSION MAGNUM REPLACEMENT IMPELLER BETTER MISSION MAGNUM REPLACEMENT IMPELLER
Product name : BETTER MISSION MAGNUM REPLACEMENT IMPELLER
Item : BT-SB-6
Country of Origin :
Brand Name :
Standard :
Packing Details :
←[Previous Product]              [Next Product]→

Details:

BETTER MISSION MAGNUM REPLACEMENT IMPELLER



BETTER Open type impeller is made of ductile iron with better wear-resistance than hard iron, and interchangeable with Mission Magnum same model and we have made the technological improvement

On the impeller by the introduced Patented Design of a Chinese specialist engineer. To use the improved impeller, the mud in the stuffing box will be relative flowing, so that the temperature caused by the seal surface frication will be lower, and the light sand partial could be took away, and then the mechanical seal’s life will be prolonged. And the inside pressure chances will reduce the mud loss when mechanical seal is out of work.



IMPELLERS

Item

MISSION

Part No.

Description

Material

Remarks

2*

19204-XX-30

641215603

Impeller,3×2×13

QT600-3

1. XX-Impeller code-First X equals dia.of impeller in inches minus 4.Therefore 10”=6,9”=5, etc…14use letter A;

2. Second X equals fractional data in 1/8’s.Therefore 1/8”=1, 1/4”=2 ,etc…Thus a 10.5” impeller is coded as 64, 12” impeller is coded as 80, 13.25” impeller is coded as 92 etc…

3. YYYthe metric diameter of impeller, therefore 12” is code as 305mm, 11” is coded as 280mm.

2*

19206-XX-30

641217005

Impeller,4×3×13

QT600-3

2*

19121-XX-30

641217831

Impeller,6×5×11

QT600-3

2*

19121-XX-30

641211602

Impeller,6×5×14

QT600-3

2*

19224-XX-30

641212105

Impeller,5x4x14

QT600-3

2*

19121-XX-30

641211602

Impeller,8×6×11

QT600-3

2*

19116-XX-30

641209903

Impeller,8×6×14

QT600-3

2*

21867-XX-30

641221007

Impeller,10×8×14

QT600-3



Please consult with our sales for further information.
