TONG DIES FOR POWER TONGS

BETTER Part No.

Dimensions

Tooth Type

OEM Reference #

Place of Use

Weight

BT16407-P-Thin

89 ( 3 ½”)

Pyramid

/

TEDA Tubing Power Tong XQ89/3YB

XQ89/3YC

/

BT16407-P-Middle

73 ( 2 7/8”)

Extra

60 ( 2 3/8”)

BT16408-P-Big arc

89-141.5

(3 ½”-5 ½”)

Pyramid

76731

TEDA Tubing Power Tong

XQ114/6YB

/

BT16408-P-Small arc

73-78

(2 7/8”)

76732

BT16408-P-I

73-78

(2 7/8”)

Pyramid

12AZ1101

TEDA Tubing Power Tong

XQ140/12Y

/

BT16408-P-II

89-114

(3 ½”-4 ½”)

12AZ1102

BT16408-P-III

121-156

(4 ¾”-6 1/8”)

12AZ1103

Note: D = Diamond Tooth Pattern, P = Pyramid Tooth Pattern, S = Straight Tooth Pattern

Diamond tooth dies are used when a more aggressive bite is required.
