Spare Parts Data sheet

Item

Qty

MISSION

Part No.

MISSION

Processing#

Description

Material

1*

1

See below

See below

Casing

QT600-3

1A

1

10399-46-1

648403012

Gasket,casing

Vellumoid

1B

12

3932-61

648402014

Nut,casing

Stl

1C

12

3862-76

648401115

Stud,casing

Stl

1D

1

8505-04-01

86485503

Plug,Casing Drain

Stl

1E

1

8505-04-01

646400507

Plug,flush line

Stl

2*

1

See below

See below

Impeller

QT600-3

2A

1

19110-72

64845082

Seal,impeller

Viton

2B

1

7300239

Washer,impeller

Stl

2C

1

7415648

Bolt,impeler lock

Stl

3*

1

22223-01-30

641116157

Stuffing box,mech.seal

QT600-3

3*

1

20614-01-30

643365042

Stuffing box,packed

QT600-3

3A

2

3861-117

648401016

Bolt,stuffing box

Stl

3B

1

19368-01

601499403

Grease fitting

Brass

4

1

20622A

641103338

Gland assy,packing

Stl 304

5A#

1

22451-1

648414308

Seal,mechanical

Tungsten

5A#

3

25014-04M-B

661007005

Packing, Shaft

Kevlar

6

2

B3701A

601102494

Bolt assy,gland

Stl 304

7

1

20612-02-33

646490557

Shaft

42CrMo

7A

1

20943-21

641102182

Sleeve,shaft,M.S.

38CrMoAl

7A

1

20613-21G-7A

641102181

Sleeve,shaft,Pack

Stl

7B

1

4372-5-21

601212392

Key,shaft

Stl

7C

1

23444-01-72

648415156

Seal,shaft sleeve

Viton

8

1

22210-1A

641116108

Deflector assembly

Composite

9

1

20618-12-1

644302499

Frame,grease lubricated

Cast iron

9A

1

8505-05

601474737

Plug,oil drain

Stl

9B

3

2538-1H

Bolt,casing jack

stl

9C

1

8505-05

601474737

Plug, Frame Drain

Stl

10A

1

20626

644303109

Cover,inboard bearing

Iron

10B

1

20625

648408706

Gasket,I.B.Brg.Cover

Vegetable fiber
